Specifications
EN-XGSFPP-OMAC Series — XGS-PON ONT in an SFP+ Stick (Transparent MAC)
Bring 10G symmetrical XGS-PON to any compatible router, switch, or server with an SFP+ port. The EN-XGSFPP-OMAC family is a compact XGS-PON ONT “in a stick” with Transparent MAC (MAC pass-through)—built for fast deployments across FTTH, enterprise edge, and mobile backhaul.
Choose your firmware path:
V2 / V2I (Standard firmware): streamlined, deployment-focused experience
V8311 / V8311I (8311 Community firmware): advanced configurability (OMCI/MIB editing, scripting, VLAN hooks, dual-bank, etc.)
Parameter Specification Form Factor SFP+ PON Standard ITU-T G.9807.1 (XGS-PON) Data Rate 9.953 Gbps Upstream / 9.953 Gbps Downstream TX Wavelength 1270 nm (Burst Mode) RX Wavelength 1577 nm (Continuous Mode) Optical Budget ≥29 dB TX Power +2.5 dBm ~ +7 dBm Receiver Sensitivity ≤ -28 dBm Connector SC/APC Fiber Type Single-mode (G.652) Host Interface SFP+ Host Speed 10G SFI (fallback to 2.5G / 1G) Power Supply 3.3V Power Consumption <3.5 W Digital Diagnostics DDM Supported Operating Temperature 0°C ~ 70°C Industrial Option -40°C ~ 85°C Supported Protocols XGS-PON (G.9807.1), XG-PON (G.987*) , OMCI, IEEE 802.3 Ethernet, IEEE 802.1Q VLAN
Features
XGS-PON ONT in SFP+ form factor — full ONT functionality integrated into a compact pluggable module
10G Symmetrical PON Access — up to 9.953 Gbps upstream / downstream
Transparent MAC Passthrough — preserves the MAC address of the connected router or host device
Multi-rate Host Interface — supports 10G SFI with fallback to 2.5G and 1G
SC/APC Optical Interface — optimized for standard XGS-PON fiber deployments
Digital Diagnostic Monitoring (DDM) — real-time monitoring of optical power, temperature, and voltage
Web-Based Management Interface — simple configuration and monitoring through a browser
Secure Remote Access Options — optional SSH, HTTPS, Telnet, and HTTP management services
Remote Packet Capture Support — advanced troubleshooting capability for network diagnostics
Multiple Authentication Modes — support for SN, LOID, SN+Password, and LOID+MAC authentication
Advanced OMCI Configuration (V8311 firmware) — editable vendor ID, OMCC version, and MIB parameters
Flexible VLAN Handling — VLAN tagging, untagging, and script-based VLAN control (V8311 firmware)
Dual-Bank Firmware Support (V8311) — safe firmware upgrades and rollback capability
Industrial Temperature Option — available models supporting -40°C to +85°C operation
Low Power Consumption — powered directly from the host device via 3.3V SFP+ interface
Applications
Deployment scenarios for this module
Residential & Multi-Dwelling Unit (MDU) Broadband
Service providers can deploy fiber directly into customer routers with SFP+ ports, eliminating the traditional external ONT.
Mobile Backhaul & Small Cells
The compact XGS-PON ONT in SFP+ format is ideal for mobile network edge deployments where space and power are limited.
Enterprise Fiber Access
Enterprises can integrate PON connectivity directly into existing network infrastructure such as switches, routers, or firewalls.
Carrier Edge & Network Labs
The EN-XGSFPP-OMAC series is well suited for carrier edge deployments and testing environments where compact, flexible fiber access is required.
Quality Certification
At E.C.I. NETWORKS, all our optical transceivers are CE, FCC, RoHS, and FDA laser compliant, meeting global standards for safety, environmental responsibility, and electromagnetic performance.
Key Certifications
Emissions & immunity compliance for IT and multimedia equipment.
Verified as unintentional radiators with SDoC available.
Safety-certified and laser-classified (Class 1).
U.S. laser safety regulations.
Free from hazardous substances and environmentally responsible.
Available on selected models per regional or customer needs.
Compliance Standards
These certifications ensure our transceivers are safe, interoperable, and built to meet the highest global compliance standards across data center, telecom, and enterprise environments.
Conflict-Free Sourcing
We comply with the SEC Conflict Minerals Rule, supporting ethical sourcing practices for minerals like tantalum, tin, tungsten, and gold.
Quality Certification
At E.C.I. NETWORKS, all our optical transceivers are CE, FCC, RoHS, and FDA laser compliant, meeting global standards for safety, environmental responsibility, and electromagnetic performance.
Key Certifications
Emissions & immunity compliance for IT and multimedia equipment.
Verified as unintentional radiators with SDoC available.
Safety-certified and laser-classified (Class 1).
U.S. laser safety regulations.
Free from hazardous substances and environmentally responsible.
Available on selected models per regional or customer needs.
Compliance Standards
These certifications ensure our transceivers are safe, interoperable, and built to meet the highest global compliance standards across data center, telecom, and enterprise environments.
Conflict-Free Sourcing
We comply with the SEC Conflict Minerals Rule, supporting ethical sourcing practices for minerals like tantalum, tin, tungsten, and gold.
Performance & Reliability
We ensure our optical transceivers deliver exceptional performance and long-term reliability through rigorous testing on industry-leading equipment.
Power & Wavelength Testing
We verify signal strength and wavelength stability to ensure seamless decoding and consistent transmission across the optical path.
Traffic Testing
All transceivers undergo bit error rate (BER) and packet loss testing to guarantee zero data loss and full compliance with Ethernet and Fibre Channel standards.
Optical Performance Validation
Our modules are evaluated for signal integrity, eye diagram clarity, and BER, ensuring stable, high-quality optical transmission in all operating conditions.
End Face Inspection
Each module's fiber interface is inspected and cleaned to eliminate contamination and physical defects -- a critical step for optimal signal performance and long service life.
Warranty & Compatibility
Warranty: 2 years (hardware defects under normal usage with default firmware)
Returns: 30 days unopened/unused, 25% restocking fee
Zero Risk
Using our transceivers does not void the warranty of your network equipment. Global OEM policies and consumer protection laws (like the Magnuson-Moss Warranty Act) prevent manufacturers from denying support based solely on the use of third-party components.
Guaranteed Compatibility
Our modules are coded and tested for seamless operation across major platforms including Cisco, Arista, Juniper, HPE, Nvidia, Huawei, and more. This rigorous validation ensures plug-and-play reliability and full compliance with OEM specifications.
Technical Support & RMA
Have an issue? We provide full technical support and hassle-free RMA on all eligible transceivers.
Q&A
Commonly asked questions
No. Under the Magnuson-Moss Warranty Act and similar global consumer protection laws, OEMs cannot void your equipment warranty simply because you use a third-party transceiver. Your equipment warranty remains intact.
Yes. Our transceivers are manufactured to the same MSA standards as OEM modules. They undergo rigorous testing for optical performance, thermal stability, and compatibility before shipping.
Yes. Our modules are coded for the specific platform you select at purchase. They are recognized natively by the switch OS without any additional configuration or commands.
No. Our transceivers meet the same IEEE and MSA specifications as OEM modules. They deliver identical optical performance, data rates, and reach characteristics.
Yes. We offer full support, RMA service, and warranty coverage on all modules.
Still have questions?
Our team is ready to help with any technical questions about compatibility or deployment.
Contact Us
Resources
Downloads and documentation
Product Datasheet
